MetaLine Series 700 – Elastomers sprayable

Process

MetaLine's cartridge spraying process is based on a novel packaging and application technology. The material is delivered ready for spraying in an airtight double-cartridge. It is only necessary to screw on the static mixer/spray-nozzle supplied. Using the MetaLine APPLICATOR S700, the cartridge's content are uniformly pressed into the static mixer, mixed thoroughly and sprayed on with air atomized through the nozzle attachement.

The user can freely determine his processing speed from 50 to 1,000 grams (0.1 to 2.2 lbs) material output per minute. This technology involves 3 different product types with divergent hardness and static friction:



MetaLine 760
  • 60 Shore A (soft)
  • high stiction
  • FDA compliant –

for rubber repairs

Product
MetaLine 785
  • 85 Shore A (medium-soft)
  • medium stiction
  • FDA compliant –

for wear protection applications

Product
MetaLine 795
  • 95 Shore A (semi-hard)
  • low stiction
  • FDA compliant –

for non-stick coatings

Product


Product Concept

  • Atomizing is similar to spray gun painting, however, it is possible to apply far greater quantities and achieve considerably higher film thicknesses.
  • MetaLine Series 700 coatings react very quickly and already 1 minute after application the material stops flowing. Owing to this, it is possible to achieve enormous film thicknesses quickly and uniformly - even on vertical surfaces or overhead.
  • The cartridge's content is not making any contact with the APPLICATOR S700 at all, as it is sprayed off directly from the packaging not traveling through the spray tool. None whatsoever equipment cleaning is requried! The one-way static mixer will be disposed of after processing. Cartridges not used up completely can be removed and reused at a later stage.
  • MetaLine Series 700 coating materials do not contain any solvents or water! They do not pose any hazard to the user during processing or curing. Nonetheless, they have to be processed in areas equipped with a suitable extraction system and respiratory masks are prescribed for the user.
  • Owing to its durability, swiftness, and cleanliness, the MetaLine concept has gained a leading position in international surface protection. Preparing the substrate thoroughly beforehand is an absolute must! Handling requires know-how and initial training is mandatory!

Ask an expert

Call +49 (0) 7034 31000 and talk to Heidrun or select here:

Whom to ask?

You can contact us in the following languages:
metaline_0035
next arrow

previous arrow
Exit full screenEnter Full screen
metaline_0035
metaline_0228A
metaline_0185N
metaline_0042A15
metaline_0093A15
metaline_0093A70
metaline_0172P
metaline_0189J
metaline_0260C
metaline_0238
metaline_0149
metaline_0002B
metaline_10009
previous arrow
next arrow

Please publish modules in offcanvas position.

Explained in simple terms...

That's how it is done – MetaLine Series 700 cartridge spray system
Large valve coated and protected with MetaLine 785 by the manufacturer
Saltwater resistant coatings – MetaLine 785 as seamless in-situ elastomerification for seawater piping in all diameters
Insulation coating – MetaLine 785 in a thickness of 1 mm had been spray applied to electrically insulate the rails
Shaft support coating – a sprayable heavy duty cavitation protection for the durable treatment of this shaft support
Rudder coating – MetaLine 785 being applied to very critical, cavitation abused areas on a bigger rudder. The MetaLine cartridge spray process proved itself to be far superior to all trowel applied epoxy systems
Valve coating – MetaLine 795 used as heavy protective coating to protect against atmospheric corrosion in tropical costal areas
Pipeline coating – MetaLine 785 is being used on site to seal and repair this sewage pipe made from concrete
Coated on site with temperatures amounting to 40°C and more than 90% humidity with MetaLine Series 700 cartridge spray system
A clear rubberlike coating of MetaLine 785 protects this Caterpillar from corrosion and increases its used sales valuecartridge spray system
Pump impeller coating – the largest pump impeller ever coated with MetaLine 785. 10 tons of steel being protected by our leading elastomeric spray technology
And that's how it is done – MetaLine cartridge spray applicator. An effective tool for everybody
MetaLine Series 700 – professional OEM-technology
